Acrylate Grout
Acrylate Grouting Material
Precision-tunable acrylate grout combining strength, flexibility, and excellent penetration for large-area sealing work.
Suitable Environment
- Wet-condition application possible
- Continuous seepage zones
01 / Features
Key Highlights
- 01Precise and adjustable reaction time
- 02Balanced strength and flexibility
- 03Suitable for large-area grouting
- 04Excellent penetration capability
- 05Designed for continuous water-stop projects
02 / Applications
Application Scenarios
- Large-area waterproofing projects
- Tunnel curtain grouting
- Diaphragm walls
- Long-distance water stop treatment
03 / Specifications
Physical Properties
- Type
- Multi-component acrylate system
- State
- Homogeneous liquid, no particulates
- Color
- Per component
- Density
- Plant-controlled (≤ 0.05 batch variance)
- Packaging Form
- Steel drum
Performance Indicators
- AppearanceHomogeneous, no particulates
- Viscosity≤ 10mPa·s
- pH value6.0 – 9.0
- Permeability coefficient< 1.0 × 10⁻⁷m/s
- Cured-body compressive strength (type I / II)≥ 200 / 400kPa
- Freeze-thaw cycle ratio (type I / II)≥ 300 / 600%
- Water-swell ratio≥ 30%
- Gel time (fast-set variant)30 – 120s
04 / Installation
Application Guide
- 01Drill or chase through the leaking section to open the injection path
- 02Pre-inject water to confirm crack network connectivity; drill additional ports if needed
- 03Use manual or electric high-pressure pump; inject at 0.2–0.6 MPa, raising pressure based on seal quality
- 04Stop injection immediately if material leaks visibly to the surface; seal the leak and resume
- 05Mix A and B in the prescribed ratio — A bucket contains promoter, B bucket contains accelerator
- 06Mix both buckets evenly and start the pump; A bucket and B bucket are interchangeable at the pump inlet
- Liquid bromide will speed up the reaction in summer — beware of premature gelling
- Acrylate gel time is typically 30–120 s under standard conditions
- Site humidity and temperature affect cure time — pick the right formulation for the conditions
05 / Storage & Safety
Transport, Storage & Safety
Storage & Transport
Store and transport away from direct sunlight and rain. Keep away from open flame and heat sources. Storage temperature ≤ 40 °C, well-ventilated.
Shelf Life
12 months from manufacture date under normal transport and storage conditions
Precautions
- Operators must wear PPE; rinse with clean water and seek medical attention on contact
- Use entire opened container; dispose of residual material per regulation
- Do not blend with other materials — contact Yifeng technical service for assistance
